AO-73 (FUNcube-1) – Image credit Wouter Weggelaar PA3WEG

Hi Folks,

It seems amazing to us that FUNcube-1 – AO73, was launched nearly one year ago, in fact at 07:10 UTC on 21 Nov 2013. The very first signals were received by ZS1LS in South Africa at 07:37 UTC and he was even able to upload the resulting data to the Warehouse so the results could be seen immediately.

We are extremely happy to say that, since then, the satellite has been performing very satisfactorily, the battery voltage doesn’t drop below 8 volts, and becomes fully charged within about 7 – 10 minutes after re-entering sunlight from eclipse.

Howard Long G6LVB working AO-73 while Ciaran Morgan M0XTD captures the downlink passband data using a FUNcube Dongle Pro+ and Microsoft Surface Tablet

On Friday 21 Nov 2014, we will be celebrating the satellite’s first birthday. To mark the occasion, we will be activating the transponder earlier than normal – late on Thursday 20 Nov, so that it will be available for use during the whole of Friday. So please make as many contacts as possible through the transponder during Friday, FUNcube’s actual birthday. You are invited to make a note of any stations worked on this day, or any other comments on the FUNcube Forum. Please use the existing “FUNcube-1’s Birthday” topic, under the Welcome heading. The URL of the Forum is http://forum.funcube.org.uk/

Please also remember the ’73 on 73′ Award which is kindly being organised by Paul Stoetzer N8HM. See https://amsat-uk.org/funcube/73-on-73-award/ for more details.

Wouter Weggelaar PA3WEG talking about FUNcube-1 to students at Abbeys Primary School in Bletchley

We would like to take this opportunity of thanking all of our ‘users’, both those who download telemetry and forwarding it to the warehouse, and of course, all users of the transponder. This telemetry data is invaluable, both as an educational resource and to enable us to see how the spacecraft systems are performing and surviving. So far we have collected almost 400MB of unique data via stations from all around the world.

Of course we are hoping that the satellite continues to function nominally for several more years to come even though we may never reach AO7’s record!

73s AMSAT-UK and AMSAT-NL

First 73 on 73 Award issued to Wyatt Dirks AC0RA

The AMSAT-UK Flickr Group is at https://www.flickr.com/groups/amsatuk/
Please upload your pictures of amateur satellites, satellite ground stations, satellite demonstrations or any other satellite related event.

73 on 73 Award https://amsat-uk.org/funcube/73-on-73-award/

Data Warehouse – Telemetry Archive http://warehouse.funcube.org.uk/

Dashboard App – Telemetry Decoder http://funcube.org.uk/working-documents/funcube-telemetry-dashboard/

AO-73 (FUNcube-1) – Image credit Wouter Weggelaar PA3WEG

FUNcube-1 was launched on November 21, 2013 and since then radio amateurs and schools have been collecting the telemetry which has been stored in the Data Warehouse.

The Data Warehouse statistics as of 21:49 GMT on October 25, 2014 were:

Number of registered users: 1286
Number of active users (data received in last two weeks): 195
Number of active users since launch: 757

Number of packets transmitted by satellite since deployment: 5865120 (1.5GB)
Number of packets uploaded by users before deduplication: 6370976 (1.63 GB)

Number of packets stored in warehouse: 1466239 (376.9 MB) which also
represents the same number of realtime data points (collected once every
5 seconds),

Whole orbit Data: 276.3 days of data (collected once every minute)
High Resolution Data: 806 hours of data (collected once every second, for a period of a minute, every other minute)

Whole orbit Data: 276.3 days of data (collected once every minute)
High Resolution Data: 806 hours of data (collected once every second, for a period of a minute, every other minute)

Recovery rates:
Realtime  (25%)
WOD (81%)
HiRes (22%)

As always, many thanks to all those who have and continue to send data.

Data Warehouse – Telemetry Archive http://warehouse.funcube.org.uk/
Dashboard App – Telemetry Decoder http://funcube.org.uk/working-documents/funcube-telemetry-dashboard/

Facebook https://www.facebook.com/amsatuk
Twitter https://twitter.com/AmsatUK

Wouter Weggelaar PA3WEG talking about FUNcube-1 to students at Abbeys Primary School in Bletchley

AMSAT-UK have uploaded a special Jamboree On The Air (JOTA) Greetings Fitter Message to the amateur satellite AO-73 (FUNcube-1).

Scouts and others can receive the message by downloading the Dashboard App software and listening to the beacon on 145.935 MHz (+/- Doppler) SSB.

What is a Fitter Message ?

‘Fitter’ is derived from ‘Twitter’. So it’s like a tweet, but via FUNcube.

It is a short (200 characters maximum) text-like message which can be uploaded to the satellite (by authorised ground stations), and transmitted several times every five minutes or so. It will continue to be retransmitted until such time as it is replaced by a new Fitter Message.
Links for tracking, downloads and other information can be found in the FUNcube-1 / AO-73 panel on the right-hand side of the AMSAT-UK homepage at https://amsat-uk.org/

Data Warehouse – Telemetry Archive http://warehouse.funcube.org.uk/
Dashboard App – Telemetry Decoder http://funcube.org.uk/working-documents/funcube-telemetry-dashboard/

AMSAT-UK on Facebook https://www.facebook.com/amsatuk
AMSAT-UK on Twitter https://twitter.com/AMSAT_UK

AO-73 (FUNcube-1) – Image credit Wouter Weggelaar PA3WEG

From the early planning stage of the project we decided that we would make telemetry information from the AO-73 (FUNcube-1) CubeSat available to end users.

Since deployment the FUNcube Data Warehouse has displayed the latest data:
• Reatime
• Whole Orbit
• High Precision
• Fitter Messages
and of course the upload rankings. Additionally we have made available small csv files for WOD and HiRes.

Starting October 14, we will be making all captured WOD available as weekly csv files.

Please see: http://warehouse.funcube.org.uk/wod.html?satelliteId=2 for the link to the downloads page. It currently up to 26/6/2014 (32 files)

The files are on average:
• 9706 lines (expected 10080) ~ 96.3% capture
• 905 KB

We will play catch up over the next few days and then automate the process.

It it really intended for consumption by an analytical suite such as MatLab, or a DIY one, in a language of your choosing. However, it can be simply graphed in Excel or Open Office Calc.

Feedback would be appreciated.

Enjoy!

73 Dave, G4DPZ
