ARISS SSTV Commemorative Activity

ISS SSTV image 2 received by Mike Rupprecht DK3WN April 12, 2016 at 1556 UT

ISS SSTV image 2 received by Mike Rupprecht DK3WN April 12, 2016 at 1556 UT

Special Slow Scan Television (SSTV) transmissions are expected to be made from the International Space Station on 145.800 MHz FM around the weekend of July 15.

In commemoration of their 20th anniversary, the ARISS team is planning to transmit a set of 12 SSTV images that capture the accomplishments of ARISS over that time.

The ARISS SSTV Blog says:

While still to be scheduled, we anticipate the SSTV operation to occur around the weekend of July 15.  We are planning for at least a 2 day operation, but are working for a potential longer operation. Note that all of this tentative and may change based on crew scheduling and
ISS operations.

Starting with our first meeting in November 1996, our joint operations on Mir, becoming the first operational payload on ISS in November 2000 to our 1103rd school contact (so far), ARISS’ accomplishments have been tremendous. We have touched the lives of many and inspired and educated countless students to pursue science, technology, engineering and math careers.

Please stay tuned as more details on our SSTV event will be communicated in the coming weeks.  Please spread the word.  And think about how you can get students in your area involved in capturing these images.  We would love to hear your stories on how that goes.

73,  Frank KA3HDO

ARISS SSTV Blog http://ariss-sstv.blogspot.co.uk/2017/06/ariss-sstv-commemorative-activity.html

How to receive ISS SSTV https://amsat-uk.org/beginners/iss-sstv/

FUNcube Satellite Status June 2017

AO-73 (FUNcube-1) – Image credit Wouter Weggelaar PA3WEG

AMSAT-UK has released the FUNcube satellite status update report for June 2017.

AO-73 FUNcube-1

The transponder is normally operational only when the satellite is in eclipse, ie the solar panels are NOT being illuminated. During weekends (from PM Fridays UTC to PM Sundays UTC) the transponder is operational 24/7.

When the transponder is switched off, the telemetry beacon is on full power, when the transponder is on the beacon it is on low power. During holidays, e.g. Christmas, New Year, Easter, etc, the transponder maybe activated for extended periods. Watch AMSAT-BB for announcements which are usually made on Friday evenings (UTC)

The nominal transponder frequencies are:

Uplink: 435.150 – 435.130 MHz LSB (Inverting)
Downlink: 145.950 – 145.970 MHz USB
Telemetry Tx: 145.935 MHz BPSK

(The passband may be up to 15 kHz higher depending on on-board temps. Lower temperatures give higher freqs!)

FUNcube-2 (aka FUNcube on UKube)

The FUNcube-2 sub-system continues to operate autonomously and, almost continuously, in amateur mode. The transponder is operational and the telemetry downlink is functioning with about 70mW output. The FUNcube-1 Dashboard does not correctly display the telemetry but it does correctly decode the data and uploads it to the FUNcube Data Warehouse from where it can be examined. Most of the real time data channels are operational and these include battery voltages, temperatures and ADCS data coming via the main On Board Computer (OBC).

The transponder is interrupted for a few seconds every 2 minutes when the other transmitter sends its CW beacon and, occasionally, for a few seconds when the main OBC reboots (approx seven times each orbit).

The nominal transponder frequencies are:
Uplink: 435.080 – 435.060 MHz LSB (Inverting)
Downlink: 145.930 – 145.950 MHz USB
Telemetry Tx: 145.915 MHz BPSK

(The passband may be up to 10kHz higher depending on on-board temps. Low
temperatures give higher freqs!)

EO79 FUNcube-3

Due to power budget constraints the transponder cannot be operational 24/7 and an orbit specific schedule has been developed. The transponder will commence operation 27 minutes after the spacecraft enters sunlight and will stay on for a period of 25 minutes. This schedule may be modified in future months as a result of experience.

The nominal transponder frequencies are:
Uplink: 435.0723-435.0473 MHz LSB (Inverting)
Downlink: 145.946-145.971 MHz USB

Further detailed info on EO79 transponder frequencies is at:
https://amsat-uk.org/2016/11/10/eo79-funcube-3-transponder-commences-regular-operation/

EO88/Nayif-1/FUNcube-5

EO88 is presently operating in autonomous mode. The transponder is operational when the satellite is in eclipse, i.e. the solar panels are NOT being illuminated.

When the transponder is switched off, the telemetry beacon is on full power, when the transponder is on the beacon it is on low power.

The transponder frequencies are:

Uplink: 435.045 – 435.015 MHz LSB (inverting)
Downlink: 145.960-145.990 MHz USB
Telemetry Tx: 145.940MHz

All FUNcube transponders are sponsored by AMSAT-UK and AMSAT-NL. We are very grateful for the assistance given by Innovative Solution In Space Bv, The Netherlands.

AMSAT-BB http://www.amsat.org/mailman/listinfo/amsat-bb

FUNcube
Yahoo Group https://amsat-uk.org/funcube/yahoo-group/
Web http://www.funcube.org.uk/
Forum http://forum.funcube.org.uk/

Amateur radio to the rescue of satellite

I-Inspire-2 is a 20 x 10 x 10cm CubeSat built by the University of Sydney in collaboration with the Australian National University and the University of New South Wales (Sydney)

WIA News reports:

On board the tiny spacecraft is an experiment, part of the QB50 project, designed to “explore the lower thermosphere, for re-entry research and in-orbit demonstration of technologies and miniaturised sensors”, as reported in earlier editions of the WIA broadcast.

Its operational frequency was coordinated by IARU to be in the satellite segment of the 70cm amateur band.

It was placed in orbit from the International Space Station in late May. The deployment was successful; however there were no signs of life when the ground stations started looking for it. The engineering group quickly tested various scenarios on the engineering model only to come to the conclusion that, due to the extended delay in the deployment, the satellite’s battery was likely to be depleted and the satellite was trapped in an endless loop, trying to deploy its antenna.

The engineering group suggested that the satellite is still listening albeit with its antennas in the stowed position. This meant that the satellite command receiver might have difficulty receiving any signals from ground control stations. A set of commands were devised which, if received, would instruct the satellite to wait until the battery is charged before attempting to deploy its antenna. Both UNSW and ANU ground stations transmitted the recovery command to the satellite; however after a week or so of no success it was decided that more transmitter power was required to overcome the lack of receiver sensitivity caused by the still stowed antenna. A request for assistance was passed to EME operators around the world and many responses were received.

The greatest hope for a successful recovery was thought to be PI 9 CAM using high power and a 25 m dish, normally used for radio astronomy but also EME. They were scheduled to transmit on the weekend of June 10-11.

On Sunday June 11, during the morning pass, Rob VK1KW reported a strong signal every 30 seconds on I-Inspire-2’s frequency. Dimitris VK1SV who is part of the ANU team, verified reception from home around midnight. The following morning Dimitris drove to the ANU ground station and was able to send commands to the satellite for the first time since it was deployed. Many other radio amateurs around the world also reported reception of the beacon. The satellite had come back to life!

This is a wonderful example of successful collaboration between radio amateurs and the academic community. If a frequency outside the radio amateur band had been used, it is doubtful that the satellite would have been brought back to life.

The crew of I-Inspire-2 wishes to thank all radio amateurs involved and is looking forward to a successful collection of data for the scientific experiment!

I-Inspire-2 official web site: http://sydney.edu.au/inspire-cubesat/project/index.shtml

( Dimitris Tsifakis VK1SV/VK2COW )

Source WIA News http://www.wia.org.au/members/broadcast/wianews/

Join Virtual Buildathon and build satellite antenna

Chertsey Radio Club is running a virtual build-a-thon to construct a dual-band satellite antenna for 2m/70cm using low-cost parts and it’s open to all.

They will be using WebEx so access to a PC/Tablet, webcam and Internet will be needed to take advantage of the sessions.

They will be starting the virtual buildathon with the small diplexer kit by HA8LFK, kits will no more than £20 depending on shipping and import tax, as always you pay what we pay, no additional costs.

Please email chertseyradioclub <at> hotmail.com to register your interest.

Further information at
http://chertseyradioclub.blogspot.co.uk/2017/06/virtual-buildathon-is-back.html

Syllabus consultation for UK amateur radio exams

A syllabus consultation is being held for the new Foundation, Intermediate and Advanced RSGB amateur radio exams.

The RSGB says:

A complete review of the syllabus for all three levels of the amateur radio examinations has been completed.

The draft of the new syllabus is now available for consultation together with a survey to capture any comments you may wish to make.

Please visit http://rsgb.org/syllabus_review to access the syllabus draft document and how to make your comments.

The section of syllabus relating to the Amateur Satellite Service can be seen on page 60 of the consultation document.

CAS-4A and CAS-4B Satellites from CAMSAT Launched

CAS-4A and CAS-4B launch on CZ-4B

CAS-4A and CAS-4B launch on CZ-4B

Two of CAMSAT’s amateur radio payloads piggybacked on the optical remote sensing micro-satellites OVS-1A and OVS-1B were launched at 0300 GMT on Thursday, June 15, 2017 from the Jiuquan Satellite Launch Center, on the CZ-4B launch vehicle. The primary payload of this launch is a hard X-ray modulation telescope satellite (HXMT).

Satellite CAS-4A/OVS-1A:
● Architecture: Micro-satellite
● Dimensions: 494Lx499Wx630H mm
● Mass: 55 kg
● Stabilization: three-axis stabilization system with its +Y surface facing the earth
● Primary Payload: optical Camera with 1.98m resolution

CAS-4A Orbit:
● Orbit type : Sun synchronization orbit
● Apogee: 524 km
● Inclination: 43°
● Period: 95.1 minutes

CAS-4A Amateur Radio Payload:
● Call sign: BJ1SK
● VHF Antenna: one 1/4λ monopole antenna with max. 0 dBi gain located at +Z side
● UHF Antenna: one 1/4λ monopole antenna with max. 0 dBi gain located at -Z side
● CW Telemetry Beacon: 145.855 MHz 17 dBm
● AX.25 4.8k Baud GMSK Telemetry: 145.835 MHz 20 dBm
● U/V Linear Transponder Downlink: 145.870 MHz 20 dBm, 20 kHz bandwidth, Inverted
● U/V Linear Transponder Uplink: 435.220 MHz

CAS-4 Satellite

CAS-4 Satellite

Satellite Name: CAS-4B/OVS-1B:
● Architecture: Micro-satellite
● Dimensions: 494Lx499Wx630H mm
● Mass: 55 kg
● Stabilization: three-axis stabilization system with its +Y surface facing the earth
● Primary Payload: optical Camera with 1.98m resolution

CAS-4B Orbit:
● Orbit type : Sun synchronization orbit
● Apogee: 524 km
● Inclination: 43°
● Period: 95.1 minutes

CAS-4B Amateur Radio Payload:
● Call sign: BJ1SL
● VHF Antenna: one 1/4λ monopole antenna with max. 0 dBi gain located at +Z side
● UHF Antenna: one 1/4λ monopole antenna with max. 0 dBi gain located at -Z side
● CW Telemetry Beacon: 145.910 MHz 17 dBm
● AX.25 4.8k Baud GMSK Telemetry: 145.890 MHz 20 dBm
● U/V Linear Transponder Downlink: 145.925 MHz 20 dBm, 20 kHz bandwidth, Inverted
● U/V Linear Transponder Uplink: 435.280 MHz

73!
Alan Kung, BA1DU

CAMSAT Press Release PDF

Keplerian Two Line Elements (TLEs) ‘Keps’ for new satellites launched in past 30 days
http://celestrak.com/NORAD/elements/tle-new.txt

CAS-4A and CAS-4B
