DIY 6 GHz comb generator

Assembled 2400 MHz Signal Source Kit

The publication Test & Measurement World recently mentioned the 2.4 GHz Signal Source Kits developed by radio amateur and AMSAT-UK member David Bowman G0MRF.

The article says:

“Most simple DIY comb generators seem to run out of steam about 1 GHz. I recently ran into David Bowman’s 2.4 GHz circuit and measured an upper usable range of about 6 GHz. While greatly attenuated above 3 GHz, this circuit should still be valuable for measuring semi-anechoic chambers in the GHz ranges.”

Read the full article at
http://www.tmworld.com/electronics-blogs/the-emc-blog/4402169/DIY-6-GHz-comb-generator

The 2.4 GHz Signal Source Kits are available from the AMSAT-UK shop at
http://shop.amsat.org.uk/shop/article_6/2.4-GHz-Signal-Source-Kits-by-G0MRF.html

Additional information on the kit is available at http://www.g0mrf.com/source2.htm
