The amateur radio CubeSat LituanicaSAT-1, call sign LY5N, was developed by students and young engineers from Vilnius University in Lithuania and should be deployed from the International Space Station (ISS) on Friday, February 28 at 0730 UT and streamed live at http://m.ustream.tv/channel/live-iss-stream
The team ask radio amateurs and SWL’s to listen for the FM Morse code beacon on 437.275 MHz after deployment and submit reports (see Tracking below). They say there will be Mission emblem stickers with signed QSL cards and for the first 10 registered reports, LituanicaSAT-1 branded note books!
The tiny satellite is just 10x10x10 cm with a mass of 1.090 kg yet it has a VGA camera and a 145/435 MHz FM voice transponder, designed and built by Lithuanian radio amateurs.
The prototype of the FM repeater has been operating in the home of its designer Žilvinas Batisa LY3H in Elektrėnai, Lithuania. Further information at http://ly3h.epalete.com/?p=303
The communications payload comprises:
• FM Morse Code Beacon 437.275 MHz LY5N
• FM Voice Repeater 145.950 MHz uplink (PL 67 Hz CTCSS) 435.180 MHz downlink
• AX.25 Packet Radio 145.850 MHz uplink 437.550 MHz downlink 9600 baud FSK, FM
LituanicaSAT-1 uses passive magnetic attitude control system consisting of permanent magnets that create a control torque and soft magnets that provide dampening torque using hysteresis effect. Following attitude sensors are implemented for attitude determination:
• PS-MPU-6000A MEMS motion sensor
• PS-MPU-9150A MEMS motion sensor
• L3GD20 MEMS three-axis digital output gyroscope
• HMC5883L three axes digital magnetometer
There are two computers in LituanicaSAT-1: the flight computer based on ARM Cortex-M4F microcontroller and secondary (back-up) computer based on Arduino ATMega 2560 microcontroller. These two computers and their periphery are laid out on different sides of one shared PCB. The flight computer is the central control unit of the satellite responsible for maintaining the normal operating mode of the satellite, monitoring and control of energy resources, control of attitude determination sub-system and performance of telecommands received from the satellite ground station in Lithuania.
The LituanicaSAT-1 team developed the secondary flight computer based on the open source hardware and software project named Arduino. This computer will ensure limited, however safe functionality of the satellite in case of failure of the main onboard computer and will also take and record the first pictures made by Lithuanians from space as well as control the radio beacon of the satellite.
There are 4 monopole antennas on LituanicaSAT-1: three UHF antennas and one VHF antenna. Each antenna is made of approx. 0.2 mm thick and 5 mm wide spring steel measurement tape. In deployed configuration, all UHF antennas are pointed towards the Z+ body axis direction and VHF antenna is pointed toward –Z body axis.
In the days after deployment LituanicaSAT-1 will be very close to the International Space Station (ISS). To determine when you’ll be able to hear the 437.275 MHz FM Morse code beacon look at the position of the ISS on either the ISS Fan Club website at http://issfanclub.com/ or the N2YO satellite tracking site at http://n2yo.com/ (tick the Draw footprint box).
Due to Doppler shift the beacon may appear to be +/- 10 kHz of the nominal frequency. Submit reception reports including small audio file or any other data online at http://www.kosmonautai.lt/en/data-submission/
• Web Google English http://tinyurl.com/KosmonautaiLituanicaSAT-1
• Wiki Google English http://tinyurl.com/WikiLituanicaSAT-1
• Facebook https://www.facebook.com/Lituanicasat1
Watch Jeffrey Manber of Nanoracks – LituanicaSAT-1 interview
The LituanicaSAT-1 mission is specially dedicated to honor the 80th Anniversary of the flight across the Atlantic by Lithuanian-American pilots Steponas Darius and Stasys Girėnas. Therefore the satellite bears the name of the original aircraft used during this historic flight – “Lituanica”.
On July 15, 1933, Steponas Darius and Stasys Girėnas took off from Floyd Bennett Field in New York in their airplane Lituanica and flew across the Atlantic Ocean, covering a distance of 6,411 kilometers without landing, in 37 hours and 11 minutes. Tragically they crashed by the village of Kuhdamm, near Soldin, Germany just 650 km from their destination of Kaunas in Lithuania.
